2 Cores-40 Cores Security Alarm Cable With AL Foil Shielded For Smart House

Product Categories
Hangzhou Aite Cable co.,Ltd.
Contact Now

2 Cores-40 Cores Security Alarm Cable With AL Foil Shielded For Smart House

  • 1
  • 2
  • 3

Brand Name : OEM Produce

Model Number : Alarm Cable

Certification : CPR

Place of Origin : Hangzhou, China

MOQ : 10km

Price : FOB Shanghai Price: 30USD/200m

Payment Terms : TT. LC

Supply Ability : 5000km/ Month

Delivery Time : 20days after deposit

Packaging Details : 100M. 200M. 300M. 1000FT. 500M. Reel

Spec : 6C 0.22mm² Shielded Security Wire

Cores Number : 2Cores-40Cores

Conductor Type : Stranded Wire

Inner Conductor : CCA/ BC/ TC

Shield : AL Foil and Earth Wire

Jacket Color : White/Gray/ OEM

Usage : Door Bell， Smart House

Packing : 100M Reel or Customized

Contact Now

6C 0.22mm² Security and Alarm Cable AL Foil Shielded Flexible Bare Copper

C: Structure of unshielded 0.22mm² soft alarm cable
Serial NO. Section Specification Overall Diameter(mm)
C-01 2*0.22mm² 2*7/0.20 3
C-02 4*0.22mm² 4*7/0.20 3.5
C-03 6*0.22mm² 6*7/0.20 4.1
C-04 8*0.22mm² 8*7/0.20 4.5
C-05 10*0.22mm² 10*7/0.20 5.2
C-06 12*0.22mm² 12*7/0.20 5.4
C-07 14*0.22mm² 14*7/0.20 5.8
C-08 20*0.22mm² 20*7/0.20 6.8
C-09 30*0.22mm² 30*7/0.20 8.5
C-10 40*0.22mm² 40*7/0.20 10
C-11 2*0.5+2*0.22mm² 2*16/0.20+2*7/0.20 3.9
C-12 2*0.5+4*0.22mm² 2*16/0.20+4*7/0.20 4.5
C-13 2*0.5+6*0.22mm² 2*16/0.20+6*7/0.20 4.9
C-14 2*0.5+8*0.22mm² 2*16/0.20+8*7/0.20 5.7
C-15 2*0.5+10*0.22mm² 2*16/0.20+10*7/0.20 6
C-16 2*0.5+12*0.22mm² 2*16/0.20+12*7/0.20 6.3
C-17 2*0.75+2*0.22mm² 2*24/0.20+2*7/0.20 4.2
C-18 2*0.75+4*0.22mm² 2*24/0.20+4*7/0.20 4.9
C-19 2*0.75+6*0.22mm² 2*24/0.20+6*7/0.20 5.3
C-20 2*0.75+8*0.22mm² 2*24/0.20+8*7/0.20 6.2

Electrical Characteristics

Temperature Rating -20℃ to 60℃
Operating Voltage 24/12V
DC Resistance per Conductor@ 20℃ 6.32 Ohms/1M’Nom

2 Cores-40 Cores Security Alarm Cable With AL Foil Shielded For Smart House2 Cores-40 Cores Security Alarm Cable With AL Foil Shielded For Smart House2 Cores-40 Cores Security Alarm Cable With AL Foil Shielded For Smart House

If you have technical support from an engineer, please let us know the type of cables you need, the inner conductor, the braiding coverage, the jakcet material and color, the packing length and design, and the application. We will help you choose the most suitable cable.

If you are not sure about certain specifications of the electric cables, please let us know your inquiry and we are very happy to give you professional technical advice and support services. Our company offer specific cables and wires consulting, design, OEM and manufacturing based on the customer's requirements and application scenarios to help customers create more business opportunities.
